Ka Quad-band EXT LNB
| Part number | RQ9000X |
|---|---|
| Input Frequency | None: 17.0 - 18.0 GHz 18.0 - 19.0 GHz 19.0 - 20.0 GHz 20.0 - 21.0 GHz 1: 17.2 - 18.2 GHz 18.2 - 19.2 GHz 19.2 - 20.2 GHz 20.2 - 21.2 GHz 2: 17.0 - 18.0 GHz 18.0 - 19.0 GHz 18.5 - 19.5 GHz 19.5 - 20.5 GHz |
| LO Frequency | 16.05 GHz 17.05 GHz 18.05 GHz 19.05 GHz 16.25 GHz 17.25 GHz 18.25 GHz 19.25 GHz 16.05 GHz 17.05 GHz 17.55 GHz 18.55 GHz |
| LO Stability | Phase locked to EXT Ref |
| NF / NT | 1.8dB |
| Phase Noise @1KHz | -70dBc |
| Gain | 58dB ±2.5dB max |
RQ9000X
Ka Quad-band EXT LNB
Ka Quad-band EXT LNB
첨부파일
- Ka Quad-band EXT LNB_RQ9000X_V1.5_2508.pdf (381.1K) 8회 다운로드 | DATE : 2025-10-01 10:12:56
