C-band BPF
| Part number | BPF-3550-300 BPF-3950-300 BPF-4050-300 BPF-4650-300 |
|---|---|
| Frequency | 3.4 - 3.7 GHz 3.8 - 4.1 GHz 3.9 - 4.2 GHz 4.5 - 4.8 GHz |
| Bandwidth | 300 MHz |
| In-band IL | 0.5dB |
| Rejection | 25dB @CF ±230MHz 60dB @CF ±315MHz |
| IL @10MHz | N/A |
| In / Out | CPR229 |
BPF-CF-300
C-band BPF
C-band BPF
첨부파일
- BPF-3550_-300-C-band BPF _Other Frequencies are available.pdf (111.3K) 4회 다운로드 | DATE : 2025-10-03 11:36:08
