Ka Tri-band Auto Ref LNB
| Part number | RT9315A-ISO |
|---|---|
| Input Frequency | 17.7 - 18.7 GHz 18.45 - 19.45 GHz 19.2 - 20.2 GHz |
| LO Frequency | 16.75 GHz 17.5 GHz 18.25 GHz |
| LO Stability | ±1.5ppm (over temperature) ±3.5ppm (long-term stability) |
| NF / NT | 1.5dB |
| Phase Noise @1KHz | -70dBc |
| Gain | 55dB ±1.5-3dB max |
RT9315A-ISO
Ka Tri-band Auto Ref LNB
Ka Tri-band Auto Ref LNB
첨부파일
- Ka Tri-band Auto Ref LNB_RT9315A-ISO_V1.1_2508.pdf (253.8K) 190회 다운로드 | DATE : 2025-08-21 16:52:19
